WS-1000G Gantry Heavy Duty Scrap Metal Shear with 1000 Ton Cutting Force and 2100mm Blade for Industrial Scrap Processing
商品の詳細
| モデル | WS-1000G | 構造タイプ | ゲントリーフレーム |
|---|---|---|---|
| 最大切断力 | 1000トン | 刃の長さ | 2100 mm |
| せん断の高さ | 420/500のmm | マックス鋼板 | 厚さ80mm |
| マックス丸鋼 | φ150mm | 総電力 | 275のkw |
| 制御システム | PLC タッチ スクリーン + リモート | 冷却 | 水冷チューブシステム |
| ハイライト | Gantry Frame Metal Shear,2100mm Heavy Duty Cutter,1000 Ton Scrap Processor |
||
製品の説明
WS-1000G Gantry Heavy Duty Scrap Metal Shear 2100mm Blade 1000 Ton Cutting Force Steel Plate Processing
WS-1000G Gantry Type Heavy Duty Scrap Metal Shear
The WS-1000G represents a departure from conventional container-type shears, featuring a robust gantry frame structure engineered for extreme-duty scrap processing. With 1000 tons of cutting force and a massive 2100mm blade, this machine handles oversized scrap that standard shears cannot process — including heavy structural steel, railway tracks, thick ship plates, and industrial machinery remnants.
Key Advantages of Gantry Design
- Superior Structural Rigidity: Heavy steel gantry frame withstands extreme lateral forces without deformation
- 2100mm Extended Blade: 30% longer than standard container models for processing oversized materials
- 1000 Ton Cutting Force: Capable of shearing steel plates up to 80mm thick and round steel up to Φ150mm
- Large Feed Opening: 3500mm x 2500mm hopper accommodates bulky scrap without pre-processing
- Twin Shear Cylinder Design: YG500/320 cylinders with 5000kN x 2 force for balanced cutting
- Industrial Grade Hydraulics: Heavy-duty Rexroth-type variable displacement pumps for continuous operation
Applications
Designed for heavy industrial applications including ship dismantling yards, large-scale steel mills, railway scrap processing, bridge demolition recycling, and heavy machinery disposal facilities.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | WS-1000G |
| Structure Type | Gantry Frame |
| Max Cutting Force | 1000 Tons |
| Blade Length | 2100 mm |
| Shear Height | 420/500 mm |
| Cutting Speed | 2-3 times/min (load) |
| Processing Capacity | 15-25 tons/hour |
| Total Power | 275 KW |
| Shear Cylinder | YG500/320 x 2 (5000kN each) |
| Press Cylinder | YG320/250 (2000kN) |
| Max Steel Plate Thickness | 80 mm |
| Max Round Steel Diameter | Φ150 mm |
| Feed Opening | 3500 x 2500 mm |
| Hydraulic System Pressure | ≤ 31.5 MPa |
| Control System | PLC Touch Screen + Remote Control |
| Cooling System | Water Cooling with Tube Cooler |
| Power Supply | 380V/3P 50Hz (Customizable) |
| Machine Weight | 68 Tons |
| Overall Dimensions | 15000 x 3500 x 4200 mm |
Our Service
- 24/7 online technical support with remote diagnostics
- One year comprehensive warranty with lifelong maintenance
- Free spare parts for manufacturing defects within warranty
- On-site installation, commissioning, and operator training available
- Custom engineering solutions for specific scrap processing requirements
Contact our engineering team for a detailed proposal and site assessment.
